DVC853
■ 966W (2208W boost)
■ Wide range input
■ High efficiency – typ. 92%
■ Short-circuit, no load and over temperature protection
■ IP-protection class IP54
■ Parallel connectable
■ Galvanical isolated switching regulator
■ Particularly flat and compact design
■ On request: Changed input voltage range
● Typelist:
| Type | Input voltage | Output voltage | Output current | Cat. no. |
|---|---|---|---|---|
| DVC853-48/80-13,8 | 48-80VDC | 13,8VDC | 70A (Boost 160A t<= 4s) | 105149 |
| DVC853-48/80-13,8-v2 | 48-80VDC | 13,8VDC | 70A (Boost 160A t<= 4s) | 105214 |
